Description
Features
- Two sets of rollers, dual heated rollers on the top and top heated roller on the bottom.
- Laminate/encapsulate on the top rollers and mount on bottom rollers without re-webbing the machine.
- Foot control for hands-free operation.
- Swing-out mandrels for roll changes.
- Digital touch screen.
- Photoelectric eye and emergency stop buttons for operator safety.
- Vacuum feed table holds media in place before entering the laminator.
Specifications
- Working Width: 43″
- Laminator Width: 62″
- Height: 53″
- Depth: 43″
- Net Weight: 850 lbs
- Shipping Weight: 1100 lbs
- Speed: Bottom Roller – 1 fpm
- Maximum Temperature: 230° F
- Maximum Aperture: 1/4″
- Roller Diameter: 5 1/2″
- Air: N/A
- Electrical: 220V single phase 30 amps w/neutral Foot Pedal
Made in the USA
